The Archer line of receivers has been enhanced further with the addition of the new Archer Plus Series.
The Archer Plus Series receivers include some new features. Firstly the enhanced anti-RF-Interference offers a more stable RF performance; this is in addition to the existing anti-interfere performance for spark ignition engines. The Plus series receivers work with both ACCESS and ACCST D16 modes, where the RF protocol is matched during the binding process on the transmitter. In ACCESS mode, these receivers not only feature OTA wireless firmware upgrades, increased range, and telemetry performance; they support even more functions like configurable telemetry power (RS), S.Port / F.Port / FBUS switching, and VFR indicators.
- Tiny and super lightweight
- S.Port / F.Port / FBUS (Configurable via S.Port)
- Over-The-Air (OTA) FW update
- SBUS Out port (Supports 16CH / 24CH mode)
- SBUS In port (Supports Signal Redundancy)
- Inverted S.Port
- Dimension: 16*11mm (L*W)
- Weight: 1.3g
- Operating Voltage: 3.5-10V
- Operating Current: 60mA@5V
- Antenna Connector: IPEX4
- Control Range: Full range* with telemetry
(* Full Range: ≥2km, the control range may vary based on local conditions.) - Compatibility: All FrSky ACCESS/ACCST D16 transmitters.
